Manufactures

Mirabel Energy is North America’s go-to source for premium low and medium voltage cable, with manufacturing rooted in South Korea and logistics optimized for the U.S. market. Competing directly with the largest global players—Prysmian, Southwire, PYL, and Nexans—Mirabel delivers the same high-caliber performance, but with faster lead times, better service, and more aggressive pricing.

From utility-scale projects to commercial, industrial, mining, and marine applications, Mirabel’s UL-listed cable is built for real-world performance, not excuses.

 Product Portfolio

🔹 Low Voltage Building Wire

• THHN/THWN-2 copper & aluminum (600V)
• XHHW-2 (copper/aluminum)
• NM-B, UF-B residential cables
• Rated for 600V applications in conduit, tray, or direct burial
• Available in solid and stranded constructions

• Copper & aluminum up to 600V/1kV
• Type MC / MC-HL / VFD options available
• Shielded & unshielded configurations
• Industrial controls, cable tray, and open wiring applications
• Oil, sunlight, and chemical resistant jackets

• SOOW, SEOOW, SJOOW, SJEOOW
• Extreme duty & high-flexibility for commercial, stage, and mining uses
• -40°C to 90°C rated / Water, oil, abrasion resistant
• Heavy-duty construction for mobile equipment

• TR-XLPE & EPR Insulated, 5kV, 15kV, 25kV, 35kV
• Copper tape or concentric neutral shielding
• Jacketed or non-jacketed, direct burial or conduit use
• UL 1072 / AEIC / ICEA-compliant
• Designed for utility feeders, substations, and switchgear connections

• Outdoor & indoor/outdoor fiber
• Loose tube, armored, dielectric
• Single-mode and multi-mode
• For backbone utility communication & C&I networks

• Mining cable: Type G-GC, SHD-GC, high ampacity and impact resistance
• Marine cable: Tinned copper, flexible armoring, halogen-free
• Renewable cable: Solar PV (UL 4703), wind tower flexible harnesses
• Custom designs available for OEM, data center, battery storage, and EV charging infrastructure

Arcova Energy is a rising force in North America’s T&D supply chain, delivering high-performance arresters, insulators, cutouts, and grid hardware trusted by utilities, contractors, and EPCs. Backed by global manufacturing and anchored by U.S.-based QA, testing, and logistics, Arcova delivers the reliability of big names like Hubbell, MacLean, PLP, and TE—with the speed, pricing, and focus they can’t match.

We don’t just sell components—we help protect the grid. Every unit is built to ANSI standards, tested under load and stress, and designed for long life in harsh field conditions.

• Ratings from 3 kV to 198 kV MCOV
• Polymer-housed ZnO gapless design
• Station class, intermediate, and distribution class
• Options: bracket-mounted, transformer-mounted, line-terminating
• IEEE C62.11 / IEC 60099-4 / ANSI tested

Insulators

• Polymer & Composite insulators (10kV – 765kV)
• Station post, line post, pin type, suspension, and deadend
• Designed for pollution, coastal, and cold-weather conditions
• Hydrophobic silicone rubber with UV and tracking resistance
• ANSI, IEC, and CSA certified options

• Up to 38kV, 200A/300A interrupting
• Porcelain and polymer body options
• Loadbreak and solid blade designs
• Interchangeable with major U.S. specs (Hubbell/ABB style)
• Type-tested to ANSI C37.41 / C37.42

• Clevises, eye bolts, brackets, suspension clamps
• Guy strain insulators, vibration dampers, and spacers
• Hot-dip galvanized or stainless options
• Targeted for substation and transmission line builds

Have you wondered how AI will affect your industry, your organization, or even your career? If you are involved with NERC compliance efforts, AI has begun to work its efficiency magic in your world.  For example, imagine software that can run  Inventory, PRC-005, FAC-008, PRC-024-3 and CIP-002 checks for you, scheduled or ad-hoc, providing your team an actionable, time-stamped output report of the findings!

data phleet AI-driven automation (“dp: Bots”) can perform your most difficult, labor intensive, mundane compliance processes (e.g., compliance audits, reports, ) for you. But, dp: Bots can do it faster and more consistently than people – and they don’t mind doing lots and lots of mundane, repetitive tasks – day after day after day, allowing you to return to the higher value-ad work you enjoy and your company needs!

Maximize Human Capital

Re-allocate resources to greater value-add activities: Save $ thousands in reduced consulting/auditing fees.

Mitigate Risk

Reduce time-to-discovery of reportable issues to negligible levels: Potentially save $ millions.

Take NERC Compliance Above and Beyond!

Evolve from Crisis Management to:

-  Proactive Leadership / Culture of Compliance with ongoing auditing (UNLIMITED use licenses)

-  Strengthen compliance posture with standards organizations → greater audit leniency.

-  data phleet creates an “always-available” repository for up-to-date compliance information – “Living RSAWs”

With this partnership, GCP combines 25+ years of EPC and utility expertise with Data Phleet’s cutting-edge technology to deliver:
✅ Streamlined NERC compliance (PRC-005, CIP, FAC, TPL)
✅ Reduced risk + audit readiness
✅ Smarter, more efficient compliance programs

We see Data Phleet as a premier branded partner of GCP and are proud to introduce their solutions to our customers across utilities, industrials, and data centers worldwide.

👉 Learn more about Data Phleet: https://dataphleet.com/

IAC Electricals Pvt Ltd is a globally recognized manufacturer of power transmission and distribution hardware fittings engineered for durability, performance, and compliance. From low voltage distribution lines to 800kV EHV networks, IAC delivers field-proven solutions that power infrastructure across 45+ countries.

Product Specialties Include:

• Insulator hardware fittings for phase conductors and ground wire
• Accessories for HTLS conductors and OPGW cables
• AB cable and covered conductor accessories
• COmplete range of distribution line fittings

With a 150,000 sq. ft. advanced manufacturing facility in Kolkata, India, IAC designs and produces all components to IEC, ASTM, BS, and DIN standards, with in-house lab testing and robust quality control.

Why IAC?
✔ Global standards, local agility
✔ Voltage range from 440V to 800kV
✔ On-time delivery, every time
✔ Trusted by EPCs, utilities, and OEMs worldwide

HaloPhase's technology provides continuous, real-time thermal monitoring and fault detection for critical power infrastructure assets including power transformers, substations, transmission and distribution lines, and utility-scale solar installations. Unlike traditional infrared thermography — which relies on periodic manual inspections — HaloPhase delivers 24/7 automated monitoring that detects pre-fault conditions and performance degradation before they escalate into costly failures.

Key capabilities include:

• 4D Thermographic Sensing — Integrating spatial, temporal, and spectral data for comprehensive asset health insights that conventional IR methods cannot provide
• Dynamic Line Rating (DLR) — Real-time ampacity monitoring for transmission conductors, helping utilities relieve grid congestion and reduce renewable energy curtailment
• Utility-Scale Solar Monitoring — Full PV system performance analysis that identifies module-level underperformance and balance-of-system faults, reducing power losses by up to 25%
• Substation & Transformer Monitoring — Continuous thermal profiling of bushings, load tap changers, cooling systems, and lightning arrestors

Daelim manufactures a comprehensive line of UL-listed three-phase and single-phase pad-mounted transformers for underground distribution systems.

Three-Phase Pad-Mounted Transformers

• Voltage: Up to 44 kV (HV side)
• Ratings: 75 kVA to 10,000 kVA (10 MVA)
• Configurations: Dead-front and live-front; radial feed and loop feed
• HV Bushings: 200A and 600A load-break bushing inserts with bushing wells and dead-break elbow connectors; 900A options available for BESS applications
• Winding Material: Copper or aluminum
• Insulating Fluid: Mineral oil (ONAN) or vegetable oil (FR3/KNAN)
• Standards: IEEE C57.12.34, CSA C227.4, DOE 2016 efficiency, ANSI/IEEE C57.12.00
• Accessories: ABB, Eaton, and Qualitrol components; automatic pressure relief valve, vacuum pressure gauge, temperature indicator, oil level gauge, tap changer (panel-mounted cage switch with multiple positions)
• Coatings: ISO 12944-1 compliant paints and varnishes
• Applications: Data centers, blockchain/cryptocurrency mining, BESS, utility distribution, solar PV, commercial and industrial buildings, oil and gas
• Production Capacity: 300+ units/month
• Lead Time: 8–14 weeks custom; in-stock units available for immediate shipment (4–8 weeks for standard configurations)

Single-Phase Pad-Mounted Transformers

• Ratings: 15 kVA to 250 kVA
• Voltage: Up to 24.94 kV (HV side)
• Configuration: Dead-front, radial or loop feed
• Standards: ANSI/IEEE C57.12.00, C57.12.20, C57.12.38, C57.12.90, CSA, DOE 2016
• Applications: Residential distribution, commercial areas, underground systems

Daelim produces both conventional and completely self-protected (CSP) single-phase pole-mounted transformers, along with three-phase pole-mounted units.

Single-Phase Pole-Mounted Transformers

• Ratings: 10 kVA to 333 kVA (standard 5–167 kVA; custom up to 333 kVA)
• HV Voltage: 2.4 kV to 34.5 kV
• LV Voltage: 120/240V, 240/480V, 277V, 347V, 347/600Y, and other configurations
• Types: Conventional and CSP (Completely Self-Protected)
• CSP Features: Integrated surge arrester (HV side), circuit breaker (LV side), and built-in protective fuse — eliminates need for additional external protective devices, reducing installation cost
• Winding Material: Copper or aluminum
• Polarity: Additive or subtractive
• Tap Changer: 5-position internal tap changer for voltage regulation
• Standards: ANSI/IEEE C57.12.20, CSA C2.1, CSA C2.2, DOE 2016, CSA C802.1 efficiency
• Certifications: UL, cUL, CSA, SGS, CESI
• Lead Time: 6–10 weeks

Three-Phase Pole-Mounted Transformers

• Ratings: 15 kVA to 500 kVA
• Standards: ANSI/IEEE, CSA, IEC

• UL / cUL Listed (full pad-mounted transformer series)
• CSA Certified
• CESI Third-Party Testing
• SGS Third-Party Testing
• ISO 9001 Quality Management
• Design Standards: ANSI/IEEE C57.12.00, C57.12.20, C57.12.34, C57.12.38, C57.12.90, CSA C2.1, C2.2, C227.4, DOE 2016 Energy Efficiency, NEMA, IEC 60076

VANKAL Manufactures Transmission Line Towers (66 kV – 765 kV)Lattice towers for HV/EHV/UHV transmission including suspension, tension, angle, and terminal configurations in twin, quad, and hex conductor arrangements. Manufactured under the DuraTrans brand.

High Masts & Poles (DuraMast)High masts up to 40 meters, stadium lighting masts, flag masts, street lighting poles, and decorative poles for airports, highways, stadiums, and urban installations.

Traffic & Gantry StructuresF-type cantilevers, highway gantries, crash barriers, and signage structures for EPC road and infrastructure contracts.

Railway Electrification Structures (DuraRail)OHE masts and structures for mainline electrification, dedicated freight corridors, and urban metro/monorail systems. Approved by the Central Organisation for Railway Electrification (CORE) and Rail Vikas Nigam Limited (RVNL).

Solar Mounting Structures (DuraSolar)Complete range of ground-mount module mounting systems including C Channel, Z Channel, Equal Angle, Sigma Section, purlins, and strut channels for utility-scale PV installations.

Monopoles & Telecom TowersGround-based towers, rooftop structures, and monopoles for mobile networks, IoT, smart cities, and emergency communications.

Rural Electrification StructuresHot-dip galvanized fabricated steel structures for 11 kV distribution networks with 20,000+ MT/year capacity.

LS Electric — Portfolio Summary (for reference)

Founded in 1974 and headquartered in Seoul, LS Electric is one of Korea's largest power equipment manufacturers with a growing North American footprint. Their product portfolio spans the full transmission-to-distribution stack:

Transmission & High Voltage

• Gas Insulated Switchgear (GIS) — operating since 1980, their core HV competency
• Ultra-High Voltage Transformers (UHV/HVDC) — Korea's only production base for HVDC transformers, with a new $68.5M Busan facility tripling UHV transformer output capacity The Korea Herald
• Dead Tank Breakers (245kV & 362kV) — currently in development phase, type tests targeted 2026

Medium Voltage Distribution

• MV Switchgear and Ring Main Units (RMU)
• Vacuum Circuit Breakers (VCB)
• Load Break Switches, Power Fuses, Auto Load Transfer Switches
• Underground distribution switchgear designed to ANSI/IEEE standards for North American utility and facility integration Industry EMEA

Low Voltage

• Air Circuit Breakers (ACB) — manufactured at their Bastrop, Texas facility, UL 1066 and ANSI C37 certified Panel Builder US
• Molded Case Circuit Breakers (MCCB), Miniature Circuit Breakers (MCB)
• Contactors, Overload Relays, Surge Protective Devices

Grid Systems & Solutions

• HVDC Systems, FACTS, Energy Storage Systems (ESS)
• Arc Protection Systems, Railway Systems
• Smart Grid / Microgrid solutions — recently supplying complete low-to-high voltage power systems for US hyperscale data centers, including switchgear and transformers for AI/ML facilities

TARIL is GCP Energy’s premier partner for power transformers—recognized globally for engineering precision, manufacturing scale, and uncompromising quality. Headquartered in Ahmedabad, India, TARIL operates three world-class, ISO-certified production facilities and has delivered over 12,000+ transformers across 40+ countries, including North America, the UK, and the Middle East.

With in-house design, testing, and a commitment to innovation, TARIL offers one of the widest product portfolios in the industry, serving transmission, distribution, generation, industrial, and renewable energy sectors.

🔹 Power Transformers

• Up to 1200 kV AC
• Ratings up to 500 MVA
• Auto, generator step-up (GSU), interconnecting & grid transformers
• ONAN/ONAF/ODAF cooling types

🔹 Distribution Transformers

• Ratings from 11 kV to 66 kV, up to 25 MVA
• Oil-immersed and dry-type
• Copper or aluminum wound
• Hermetically sealed & conservator types

🔹 Furnace & Rectifier Transformers

• Steel, arc, and induction furnace transformers
• Rectifier duty for electrolysis, traction & industrial applications
• High-current, low-voltage capability

🔹 Trackside Traction Transformers

• For railway & metro systems
• High reliability for demanding transport networks

🔹 Solar & Wind Application Transformers

• Inverter-duty transformers
• Skid-mounted and pad-mount options
• Designed for harmonic loads and variable frequency

🔹 Special Transformers

• Mobile substation transformers
• Earthing transformers
• Shunt reactors
• Converter transformers for HVDC

• Vertically integrated: core cutting, winding, tank, testing all in-house
• Export-ready: proven installs in Canada, UK, Middle East, Africa
•  Custom designs for EPCs, IPPs, utilities, renewables, and substations
•  Modern type testing labs per IEC, ANSI, and IEEE standards
•  Fully compliant with ISO 9001, ISO 14001, ISO 45001, BIS, CE, NABL
